Frequency (MHz) / Attenuation (dB/100m)

30 (MHz) ~ 2.2 (dB/100m)
50 (MHz) ~ 2.9 (dB/100m)
150 (MHz) ~ 5.0 (dB/100m)
220 (MHz) ~ 6.1 (dB/100m)
450 (MHz) ~ 8.9 (dB/100m)
900 (MHz) ~ 12.8 (dB/100m)
1500(MHz) ~ 16.8 (dB/100m)
1800(MHz) ~ 18.6 (dB/100m)
2000(MHz) ~ 19.6 (dB/100m)
2500(MHz) ~ 22.2 (dB/100m)
5800(MHz) ~ 35.5 (dB/100m)

Center conductor

2.77mm CCA

Dielectric

7.24mm FPE

Shielding foil

AL/PE

Outer conductor

192x0.16mm TC

Jacket

10.29mm PVC

Capacitance

80pF/m

Impedance

50 +- 3 Ohms

Screening efficiency

>100dB

Min. bending radius

5 x diameter of cable

Velocity ratio

0.86

Reel length

305m

Operating temperature

-40~+85
